iD-25

iD-25

Electronic Drum Amplifier

• V5.0 Bluetooth connection with switch button

• Aux connector, Level control

• Volume control, 3 bands EQ

• 8 inch/50 Watt low frequency speaker and 2 inch/15 Watt high frequency speaker

• 25 Watt Output

• 5.5 inch/35 Watt low frequency speaker and 1.5 inch/10 Watt high frequency speaker

‍iD-25 Manual Download

iD-25 Product Manual

• Rated Power: 25W

• Peak Power: 50W

• Speaker Unit: Woofer 5.5” (35W) + Tweeter 1.5” (10W)

• Adapter: Input: AC 100-240V

• Output: DC 13.8V 2000mA (27.6W) / DC 17.5V 2000mA (35W)

Channel 1 - Instrument Channel

• Input Method: 1/4” (6.35mm) audio cable (Guitar Cable)

• Signal-to-Noise Ratio: 90dB

• Input Impedance: 47kΩ

• Equalization:

• Bass: ±9dB at 40Hz

• Middle: ±9dB at 1.6kHz

• Treble: ±9dB at 15kHz

Channel 2 - Accompaniment Channel

• Input Method: 3.5mm Stereo Audio/Bluetooth

• Signal-to-Noise Ratio: 95dB

• Input Impedance: 68kΩ

• Bluetooth: Version 5.0

• Barrier-Free Effective Range: 15 meters

• Frequency Response: 20Hz-20kHz

• Net Weight: 3.5kg

• Gross Weight: 4kg

• Package Dimensions: L310 x W270 x H280mm
