iC-150

iC-150

PA Speaker

• V5.0 Bluetooth connection

• 2 Inputs(1/4"(6.3mm) and XLR) for Instrument/Microphone, 2 bands EQ, 2 independent Reverb, Aux in, 3 Volume controls for each channel

• Line out for multiple Amps connection

• USB Type-A connector for charging/firmware update

• 6.5 inch woofer low frequency speaker and 3x2.75 inch high frequency speakers

• 6000mAh Lithium Battery

iC-150 Manual Download

i‍C-150 Product Manual‍

• System Type: 2-way vented enclosure with high-frequency array

• High-Frequency Device: 3 x 2.75” HF speakers

• Low-Frequency Device: 1 x 6.5” woofer

• Frequency Response: (-3 dB) 60 Hz - 18 kHz

• Max SPL: 115 dB

• Coverage Angle (H x V): 120° x 50°

• HF Continuous Power: 50 W (class D)

• LF Continuous Power: 150 W (class D)

• Input Connectors: 2 x XLR/TRS combo (balanced); 1 x 3.5 mm stereo jack

• Output Connectors: 1 x 6.35 mm jack (unbalanced); 1 x USB type A charge port

• Input Channels: 2 x MIC/LINE; 1 x LINE/BT

• DSP: 32-bit DSP, 24-bit A/D-D/A

• Bluetooth: 5.0, audio streaming

• Enclosure Material: Polypropylene

• Finish: Black textured

• Grille Material: Powder-coated steel

• Handles: 1 x top

• Mounting Pole: 1 x bottom

• Dimensions (H x W x D): 320 mm x 240 mm x 290 mm

• Weight: 7.5 kg

• USB Charging: 1 A

• Power Supply: 100 - 240 V~, 50/60 Hz

• Power Consumption: 150 W

• Battery Type: Rechargeable lithium-ion 6000 mAh

• Battery Play Time (at medium level): Up to 10 hours

• Recharging Time: Less than 4 hours
